Plai

A standalone Meshtastic communicator for M5Stack CardPuter

Plai is the Ukrainian word for a mountain trail — a reliable path for your data to travel when you're off the beaten track.

Watch the demo video

Most Meshtastic nodes rely on a phone via BLE or WiFi. Plai takes a different approach: it turns the CardPuter into a self-contained messaging terminal. No phone required — just you, the LoRa CAP, and the keyboard.

Why Plai?

• Full standalone operation — No WiFi, no BLE. Direct LoRa mesh communication with on-device UI.
• Unlimited message history — The entire profile, message history, and node database live on the SD card. Storage is limited only by your card size.
• Swap and survive — Reboot or switch firmwares without losing your place in the mesh. Everything persists on SD.
• Pro navigation — PgUp / PgDown / Home / End for fast scrolling through long threads and node lists.
• Debug tools — Built-in Packet Monitor (last 50 packets) and Trace Route history (last 50 attempts per node).
• Custom alerts — Individual channel notifications with distinct sounds.
• Display sleep — Screen turns off when idle to save power; wake on keypress or radio activity.
• Emoji support — Unicode emoji rendered from PNG files on SD card (/sdcard/emoji/u<HEX>.png). Automatically falls back to a placeholder for missing glyphs. Last 10 emoji cached in RAM for fast repeated rendering.
• Stats app — Tabbed overview: node info (incl. battery), system (heap, storage, uptime, firmware version), radio, node DB (online nodes, last hour), GPS, mesh port distribution, running tasks.
• Fully compatible with Meshtastic network v2.7+
• Ping auto-reply: respond automatically when someone #ping's the channel
• New node greetings: send a welcome broadcast to the channel and/or a Direct Message when a new node appears

Apps

Nodes

Full node management with up to 1000 nodes persisted on SD card.

• Node list with signal strength, hops, battery, role, encryption indicators
• Remembers last sort order and selected node across reboots
• 9 sorting modes (name, role, signal, hops, last heard, favorites first, distance, etc.) hotkey for sorting [1..9], [TAB] to select sorting mode
• Sort by distance — [9] sorts nodes nearest-first using haversine distance from your position (fixed or live GPS). Requires position enabled in settings. Hold [CTRL] in the node list to see distance in km for each node that has a known position.
• Relay node display — see which node relayed each packet hotkey [R] to jump to relay node
• Favorite marking and quick-jump navigation hotkey [F] to toggle favorite
• Ignore nodes — mark nodes as ignored to filter their traffic hotkey [I] to toggle ignored
• Node detail view with hardware model, position, and metrics hotkey [Fn] + [ENTER] to open
• Direct Messages hotkey [ENTER] to open
• Neighbors hotkey [B] — exchange neighbor info with selected node; [Fn] + [B] open neighbors list view
• Exchange node info hotkey [N] — send node info request to selected node
• Exchange position hotkey [P] — send position request to selected node
• Traceroute hotkey [T] to open recent traceroute logs. [Fn] + [T] to start traceroute immediately
• Map view hotkey [M] — offline OSM map centered on the selected node with all node positions
• Quick messages hotkey [Q] — open quick message templates editor

Direct Messages

• Direct messaging with delivery status (pending → sent → ACK → delivered → failed)
• Channel invitation hotkey [I] — invite the node to a channel (sends #invite name=key DM)
• Full keyboard input with Cyrillic layout support
• File-backed message history on SD card
• Clear chat hotkey [BACKSPACE] to clear all messages
• Hold [CTRL] to display message info (timestamps in local time)

Traceroute

• Traceroute with hop-by-hop detail, round-trip duration, and SNR at each hop
• Success sound when a traceroute completes
• Last 50 traceroute attempts stored per node
• Visual route map with color-coded signal quality
• Press [T] to start new traceroute

Favorites list

Dedicated view of all your favorite nodes, stored persistently on SD card (favorites.dat).

• Open — [Fn] + [F] from node list
• Add/remove — [F] on a node in the main list toggles favorite status (shown in gold)
• Navigation — Arrow keys, [PgUp]/[PgDown] for page scroll, [Fn]+[↑] Home / [Fn]+[↓] End
• Jump to node — [ENTER] selects the highlighted favorite and returns to node list with that node focused
• Remove — [DEL] removes the selected favorite; [Fn]+[DEL] clears all favorites
• Favorites survive node database resets and firmware updates (file-backed)

Ignore list

Manage ignored nodes whose traffic is filtered at the mesh layer. Packets from ignored nodes are dropped before processing.

• Open — [Fn] + [I] from node list
• Add/remove — [I] on a node in the main list toggles ignored status (shown in red)
• Same navigation and shortcuts as favorites — [ENTER] jump to node, [DEL] remove selected, [Fn]+[DEL] clear all
• Ignored nodes stored in ignorelist.dat on SD; survives resets and updates

Neighbors

View direct neighbors (0-hop nodes) reported by each node via the NEIGHBORINFO_APP packet.

• Exchange — [B] from node list — sends your direct neighbors and requests theirs back
• Open list — [Fn] + [B] from node list — shows cached neighbor data for the selected node
• Navigation — Arrow keys, [PgUp]/[PgDown] for page scroll, [Fn]+[↑] Home / [Fn]+[↓] End
• Jump to node — [ENTER] selects the highlighted neighbor and returns to node list with that node focused
• Read-only — The neighbor list is populated automatically from received NEIGHBORINFO_APP packets; no manual editing
• Each node's neighbor list stored in neighbors/<node_id>.dat on SD; cleaned up when the node is deleted

Quick messages

Manage reusable message templates for fast sending in DM and channel chats.

In chat views press [Q] to open the quick message select dialog:

Select a message and press [ENTER] to edit it before sending:

Or press [ENTER] to send the selected message directly.

In Nodes view press [Q] to open the quick message editor, where you can add, edit, and delete messages:

• Open — [Q] from node list
• Add — [A] opens the text editor to create a new template
• Edit — [ENTER] opens the text editor for the selected message
• Delete — [DEL] removes the selected message (with confirmation)
• Navigation — Arrow keys, [PgUp]/[PgDown] for page scroll, [Fn]+[↑] Home / [Fn]+[↓] End
• Long messages scroll in place when selected
• Templates stored in templates.txt on SD; created with defaults on first use

Example (SD card path: /meshtastic/templates.txt):

Hello! 👋
Welcome! 🎉
Good morning! ☀
Good afternoon! 😊
Good evening! 🌙
Good night! 🌟
Sweet dreams! 😴
Welcome aboard! 🏠
Great to see you! 😄
Howdy, partner! 🤠
Yo, what's up? 😎
Peek-a-boo, who's there? 👀
Hey, champ! 💪
Hey there, buddy! 🐱
Salute, legend! 🏆
Wow, what a meeting! 🤩
Bye! 👋
See you later! 🤝
All the best! 🍀
Take care! 🫶
Have a great day! 🌈
Catch you soon! ✌
Direct! 🎯
1 hop 🐇
2 hops 🐇🐇
3 hops 🐇🐇🐇
4 hops 🐇🐇🐇🐇
5 hops 🐇🐇🐇🐇🐇

Map View

Zoom 4, style: topo

Zoom 11, style: osm

Offline map powered by OpenStreetMap raster tiles stored on SD card. Node positions are rendered in real-time from the in-memory index — zero SD I/O for markers.

• Open from node list — [M] opens the map centered on the selected node
• Open from detail view — [M] opens the map centered on the selected node
• Pan — Arrow keys [←][→][↑][↓] move the viewport by 25%
• Zoom — [Fn]+[↑] zoom in, [Fn]+[↓] zoom out (zoom 2–15)
• Center on selected node — [C] re-centers on the selected node
• Center on our node — [Fn]+[C] re-centers on our node's GPS position
• Switch map style — [TAB] cycles through map styles: osm → dark → voyager → topo
• Refresh — [ENTER] re-renders the map (picks up new node positions received via mesh)
• Back — [ESC] returns to previous view

Node markers are color-coded: selected node in orange with crosshair. Labels show the node short name (or hex ID fallback) at zoom ≥ 8 or for the selected node.

The map displays zoom level and center coordinates in the bottom corners.

Downloading Map Tiles

Use the map/download_osm_tiles.py script to download tiles for offline use. Requires Python 3 and Pillow (pip install Pillow).

Tiles are downloaded as JPEG (quality 75) in the standard {zoom}/{x}/{y}.jpg slippy map format. Low zoom levels (global overview) are downloaded worldwide; higher zooms are limited to a radius around the center point.

Available styles:

Style	Description	Best for
dark	CartoDB Dark Matter — dark background, bright features	Small TFT displays (default)
osm	Standard OpenStreetMap — light, detailed	General use
voyager	CartoDB Voyager — clean, modern look	Light theme
topo	OpenTopoMap — topographic with elevation contours	Outdoor / hiking

Examples:

# New York City, dark theme (recommended), 50km radius, zoom 2-12
python map/download_osm_tiles.py --lat 40.7128 --lon -74.006 --radius 50 --style dark

# London, standard OSM with contrast boost for small screen
python map/download_osm_tiles.py --lat 51.5074 --lon -0.1278 --radius 40 --style osm --contrast 1.3

# Tokyo, voyager style, extended zoom for city detail
python map/download_osm_tiles.py --lat 35.6762 --lon 139.6503 --radius 60 --max-zoom 14

# Kyiv, dark theme with extra brightness
python map/download_osm_tiles.py --lat 50.4501 --lon 30.5234 --radius 80 --style dark --brightness 1.2

# Berlin, topographic map for hiking
python map/download_osm_tiles.py --lat 52.52 --lon 13.405 --radius 30 --style topo

# Sydney, wide coverage with lower max zoom to save space
python map/download_osm_tiles.py --lat -33.8688 --lon 151.2093 --radius 100 --max-zoom 10

# Paris, dark theme, global tiles up to zoom 7, regional up to zoom 13
python map/download_osm_tiles.py --lat 48.8566 --lon 2.3522 --radius 50 --global-zoom 7 --max-zoom 13 --style dark

Options:

Flag	Default	Description
--lat, --lon	(required)	Center coordinates
--radius	50	Coverage radius in km for regional tiles
--min-zoom	2	Minimum zoom level
--max-zoom	12	Maximum zoom level
--global-zoom	5	Download ALL tiles globally up to this zoom
--style	dark	Map style: dark, osm, voyager, topo
--contrast	1.0	Contrast multiplier (e.g. 1.3 = +30%)
--brightness	1.0	Brightness multiplier
--saturation	1.0	Color saturation multiplier
--output	map/<style>	Output directory

After downloading, copy the style folder (e.g. map/dark/) to /sdcard/map/ on the device SD card, so tiles end up at /sdcard/map/dark/{z}/{x}/{y}.jpg. You can have multiple styles on the card and switch between them in Settings → System → Map style.

Prebuilt tiles in zoom 1-8 are available to download: Google Drive

Download, unzip then can customize with your location with bigger zoom (12-15) using the script.

Channels

Multi-channel group chat supporting up to 8 channels.

• Channel list with unread message counts
• Channel hash — Each channel shows its hash (e.g. #A3) derived from name and PSK. Lets you see how the hash depends on settings and correlate packets in Monitor (packets display the same #XX channel byte).
• Channel creation hotkey [Fn] + [SPACE] to open channel creation dialog
• Channel editing hotkey [Fn] + [ENTER] to open channel editing dialog
• Channel chat hotkey [ENTER] to open channel chat
• Individual notification sounds per channel (additional built-in alert tones)

New node greetings & #ping auto-reply

Many of us send "test test" and get no reply. Now Plai can reply automatically when you add #ping in your channel message — no more wondering if anyone's listening.

• #ping auto-reply — Add #ping anywhere in a channel message; Plai responds with a configurable template. Macros: #short, #long, #id, #hops, #snr, #rssi
• New node greetings — When a node appears for the first time (after receiving their NodeInfo), Plai can send a welcome broadcast to the channel and/or a Direct Message. Same macros apply.
• Per-channel settings — Each of the 8 channels has its own greeting and ping reply templates.

There are predefined templates for the greetings and ping reply. You can use them or enter your own custom text, holding [Fn] key.

Example: "Look who is here! #long, welcome to HAM Community of Smartwill city. I can see you with #hops hops #snr/#rssi"

Channel invitation

Share a channel with another node via Direct Message.

• Sending — In DM with a node, press [I]. Select a channel; Plai sends a DM in format #invite name=base64_psk (name max 11 chars, key base64-encoded). If the node has no public key, a confirmation is shown before sending unencrypted.
• Receiving — Enable Settings → Security → Invitations. When a DM starts with #invite and matches #invite channel_name=base64_psk, Plai creates a new channel at the first free slot. Duplicate channels (same name and key) are ignored.
• Requires at least one free channel slot to accept an invitation.

Monitor

Live radio packet feed for debugging and network analysis.

• Real-time TX/RX packet display with port labels (TEXT, POS, NODE, TELE, ROUT, TRAC, etc.)
• Channel hash (#XX) shown per packet — matches the hash in Channels for easy correlation
• Color-coded direction, node badges, and SNR indicators
• Color-coded packet ID for easy relay identification
• From/To node name resolution from NodeDB
• Scrollable packet list with detail drill-down view (extra fields, improved layout)
• Hold [CTRL] in packet list for additional fields
• Last 50 packets in a static ring buffer
• Select first item for autoscroll

Stats

Network and system statistics in a tabbed view — at a glance diagnostics without leaving the mesh.

• Node — Node ID, long/short name, role, PKI status, battery (when available)
• System — Heap (total/free/min), SD storage, uptime, date/time, firmware version
• Radio — Frequency, modem preset, waveform (SF/BW/CR), TX power, RX/TX packet counts
• Node DB — Total nodes, online (heard within the last hour), favorites, ignored, messages sent/received
• GPS — Fix quality, satellites (used/in view), coordinates, altitude, HDOP
• Mesh — Cumulative RX/TX and port distribution (Text, NodeInfo, Position, etc.) with percentages — counts reflect all packets seen by the radio stack, not a short rolling window; CRC errors shown separately
• Tasks — FreeRTOS tasks sorted by priority: name, CPU core (when enabled in IDF), priority, stack high-water mark (color hints when stack is tight)
• Tab navigation — [←][→] switch tabs; [↑][↓] scroll any tab with overflow
• Auto-refresh every 2 seconds

Settings

Complete device and mesh configuration stores in NVS. You can export and import settings to SD card for backup and restore it later.

⚠️ Mesh keys are in NVS. Don't forget to backup them to SD card if you want to keep them after firmware update!

Node database and chat history are stored on SD card and not affected by firmware updates.

• System: brightness, volume, timezone
• LoRa: region, modem preset, TX power, hop limit
• Security: channel PSK management, invitations (auto-add channels from #invite DMs), derive public key from private key (X25519)
• Node info: name, short name, role
• Position: GPS enable, fixed position, broadcast interval. GPS time sync: callback-based; system clock updated from GPS only when drift exceeds 60 seconds
• Telemetry: device metrics broadcast
• Export/Import settings to SD card
• Clear all nodes
• UI: GPS status icon in the bar only when there is a position fix; footer hints restored on multi-choice dialogs

Hardware

Required

Component	Description
M5Stack CardPuter ADV	ESP32-S3 portable terminal with keyboard
LoRa CAP	M5Stack SX1262 LoRa module (868/915 MHz)
SD Card	For profile, messages, and node database

Emoji

Plai can render emoji and other characters missing from the built-in font using PNG images stored on the SD card.

Setup

1. Create the directory /sdcard/emoji/ on your SD card.
2. Place PNG files named by Unicode codepoint in uppercase hex, e.g.:
   • u1F600.png — 😀 (Grinning Face)
   • u2764.png — ❤️ (Red Heart)
   • u1FA9B.png — 🪛 (Screwdriver)
3. Any PNG size works — images are automatically scaled to match the current font height.

If the PNG file for a codepoint is missing, the character is displayed as the font's default unknown glyph.

The last 10 emoji are cached in memory (full PNG data) so repeated renders are instant with zero SD card I/O.

Install

Beta version is available in M5Apps (Installer → Cloud → Beta tests).

Standalone version will be added to M5Burner soon.

Look for M5Apps in M5Burner.

Mesh Protocol

Built from scratch on ESP-IDF — not a fork of the Meshtastic firmware.

• Encryption: AES-CTR with channel PSK, X25519 public-key cryptography
• Multi-channel: Up to 8 channels with individual PSKs
• Routing: Hop-limit flooding (1–7 hops) with Meshtastic-compatible duplicate detection
• Reliability: ACK/NACK with automatic retries, implicit ACK via rebroadcast
• Priority TX queue: ACK > Routing > Admin > Reliable > Default > Background
• Duty cycle: Channel and air utilization tracking
• Channel activity: Detects traffic on the configured channel; default frequency slot follows the primary channel name
• TX pacing: Configurable delay for reply traffic to reduce collisions
• Roles: Telemetry broadcasts are not sent for CLIENT_HIDDEN nodes
• Multi-region: US, EU_433, EU_868, CN, JP, ANZ, KR, TW, RU, IN, and more
• Packet encoding: Nanopb (Protocol Buffers) for full Meshtastic wire compatibility

Building from Source

Prerequisites

• ESP-IDF v5.5.x (project tested with 5.5.3)
• ESP32-S3 target

Build & Flash

idf.py set-target esp32s3
idf.py build
idf.py -p COMx flash monitor

HAL Configuration

Hardware components can be individually toggled via menuconfig:

idf.py menuconfig
# Navigate to: HAL Configuration

Option	Default	Description
HAL_USE_DISPLAY	on	ST7789 display via LovyanGFX
HAL_USE_KEYBOARD	on	Keyboard input (requires I2C)
HAL_USE_RADIO	on	SX1262 LoRa radio
HAL_USE_SDCARD	on	SD card (FAT/exFAT)
HAL_USE_GPS	on	ATGM336H GPS
HAL_USE_SPEAKER	on	I2S audio output
HAL_USE_LED	on	WS2812 RGB LED
HAL_USE_BAT	on	Battery voltage monitor
HAL_USE_I2C	on	I2C master bus
HAL_USE_BUTTON	on	Home button

Project Structure

Plai/
├── main/
│   ├── apps/                  # Application layer
│   │   ├── launcher/          # Home screen & system bar
│   │   ├── app_nodes/         # Node list, DM, traceroute
│   │   ├── app_channels/      # Channel group chat
│   │   ├── app_monitor/       # Live packet feed
│   │   ├── app_stats/        # Network & system statistics
│   │   ├── app_settings/     # Configuration UI
│   │   └── utils/             # Shared UI components
│   ├── hal/                   # Hardware Abstraction Layer
│   │   ├── hal.h              # Base HAL class
│   │   ├── hal_cardputer.*    # M5Cardputer implementation
│   │   ├── display/           # LovyanGFX display driver
│   │   ├── keyboard/          # TCA8418 / IOMatrix drivers
│   │   ├── radio/             # SX1262 LoRa driver
│   │   └── ...                # GPS, speaker, LED, battery, etc.
│   ├── mesh/                  # Meshtastic protocol
│   │   ├── mesh_service.*     # Core mesh service
│   │   ├── node_db.*          # Node database (SD-backed)
│   │   ├── mesh_data.*        # Message store & packet log
│   │   └── packet_router.*    # Priority TX/RX queues
│   ├── meshtastic/            # Protobuf definitions (Nanopb)
│   ├── settings/              # NVS settings with cache
│   └── main.cpp               # Entry point
├── map/
│   └── download_osm_tiles.py  # OSM tile downloader for offline map
├── components/
│   ├── LovyanGFX/             # Display graphics library
│   ├── mooncake/              # App framework
│   └── Nanopb/                # Protocol Buffers
└── Kconfig.projbuild          # menuconfig HAL options

Support the Project

If you wish to support the project:

Ethereum (ETH): 0x249346dFCcE54B0677E6c484c7e9ea27B2424526

Credits

• Fonts: efont Unicode bitmap fonts from the Linux distribution
• Emoji: Google Noto Color Emoji — licensed under SIL Open Font License 1.1
• Icons: Free icons by Icons8
• Sounds: Epidemic Sound
• Platform: M5Stack M5Cardputer

License

This project is licensed under the GNU General Public License v3.0 — see LICENSE for details.
